Manufacturer:Yokogawa
Part#:EJX310A-EMS4G-317DD/KF21/A/C1/T04/D3/CA/Z
Availability: Usually ships in 3 to 4 weeks
Shipping: FREE FedEx /UPS Ground
Warranty: 1
year replacement Warranty
The high performance absolute pressure transmitter EJX310A features single crystal silicon resonant sensor and is suitable to measure liquid, gas, or steam pressure. The EJX310A outputs a 4 to 20 mA DC signal corresponding to the measured pressure. It also features quick response, remote setup and monitoring via BRAIN or HART communications, and diagnostics. The multi-sensing technology provides the advanced diagnostic function to detect such abnormalities as an impulse line blockage or heat trace breakage.
| Product Specification | |
| Output Signal | 4 to 20 mA DC with digital communication (HART 5 protocol) |
| Measurement span (capsule) | 1.3 to 130 kPa abs (0.39 to 38 inHg abs) |
| Integral indicator | Digital indicator |
| Mounting bracket | 316 SST or SCS14A 2-inch pipe mounting, L type (for vertical piping) |
| Process connections | With 1/2 NPT female process connector |
